MSO5000HD-BND Complete Serial Analysis Bundle

MSO5000HD-BND Complete Serial Analysis Bundle

$1,369.00 USD
$1,369.00 USD
促销 售罄

Overview

The MSO5000HD-BND unlocks the entire library of serial bus analysis options for your MSO5000HD Series oscilloscope in a single license — automotive (CAN-FD, CAN-XL, FlexRay, SENT), embedded (1-Wire, I3C), audio (Audio (I2S/LJ/RJ/TDM)), aerospace (MIL-STD-1553, ARINC 429), wireless/industrial (Manchester). One key, every protocol.

The bundle costs less than buying the included options separately. Future-proof your bench and eliminate procurement delays. The option is enabled by a software license keyed to the oscilloscope's serial number and is permanent for the life of the instrument.

Key Features

  • What's Included — 10 protocols with full trigger, decode, and search:
    • CAN-FD
    • CAN-XL
    • FlexRay
    • SENT (SAE J2716)
    • 1-Wire
    • I3C (MIPI I3C)
    • Audio Serial Bus (I2S, LJ, RJ, TDM)
    • MIL-STD-1553
    • ARINC 429
    • Manchester Encoding
  • Bundle savings — One bundle price covers every included option for considerably less than buying them separately.
  • Single License Key — One key unlocks all protocols. No managing separate licenses.
  • Future-Proof — Every protocol ready when you need it. No procurement delays.
  • Lifetime License Activation — activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.

When You Need This Option

The option fits the following workflows:

  • Multi-Domain Development — Your product uses multiple bus types. The BND covers everything from day one.
  • Test Lab Ready for Anything — Serves clients across automotive, aerospace, and consumer electronics. Every protocol available without scrambling for licenses mid-project.

Compatibility

This option is compatible with all MSO5000HD Series oscilloscopes: MSO5034HD (350 MHz), MSO5054HD (500 MHz), and MSO5104HD (1 GHz). The same capability is offered on other UNI-T oscilloscope families: MSO/UPO2000, MSO/UPO3000CS, MSO2000X, MSO3000HD, MSO3000X, MSO7000X, MSO8000HD, UPO7000L.

Frequently Asked Questions

I only need two protocols. Is the bundle worth it?

Compare the combined individual price to the bundle price. The bundle often wins at just two or three protocols — and future projects may need more.

Does BND include power analysis, AWG, or bandwidth upgrades?

No. BND covers serial bus protocols only. MSO5000HD-AWG Dual Channel 50MHz Arbitrary Waveform Generator with Bode Plot Analysis, MSO5000HD-PWR Advanced Power Analysis, MSO5000HD-TIMING Advanced Timing Analysis are separate options.

How is this option activated?

The option is enabled by a software license keyed to the oscilloscope's serial number. After purchase, the license is registered on the UNI-T website to generate the license file, which is then loaded onto the instrument from a USB drive through the option-install menu. Refer to the oscilloscope's user manual for the step-by-step procedure.

Is the license permanent, or does it require renewal?

The license is permanent — a one-time purchase that stays active for the life of the instrument. No subscriptions, no annual renewals, and no expiration.
