MSO8000HD-CTSUSB20 USB 2.0 Compliance Test Option
MSO8000HD-CTSUSB20 USB 2.0 Compliance Test Option
Overview
The MSO8000HD-CTSUSB20 adds automated USB 2.0 compliance testing — signal quality, eye diagram, rise/fall time, and impedance per USB 2.0 electrical specifications. The option is enabled by a software license keyed to the oscilloscope's serial number and is permanent for the life of the instrument.
Key Features
- USB 2.0 Compliance — Automated measurements per USB 2.0 electrical specs for HS (480 Mbps) and FS (12 Mbps).
- Eye Diagram — Pass/fail testing against USB 2.0 eye mask templates.
- Signal Quality — Rise/fall time, amplitude, and impedance measurements.
- Lifetime License Activation — activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
When You Need This Option
The option fits the following workflows:
- PHY Validation — Verify USB 2.0 PHY meets electrical specs for High Speed and Full Speed modes.
- Debug — Identify signal integrity issues causing USB enumeration failures.
Compatibility
This option is compatible with the MSO8000HD Series: MSO8804HD (8 GHz).
Frequently Asked Questions
How is this option activated?
The option is enabled by a software license keyed to the oscilloscope's serial number. After purchase, the license is registered on the UNI-T website to generate the license file, which is then loaded onto the instrument from a USB drive through the option-install menu. Refer to the oscilloscope's user manual for the step-by-step procedure.
Is the license permanent, or does it require renewal?
The license is permanent — a one-time purchase that stays active for the life of the instrument. No subscriptions, no annual renewals, and no expiration.
