Overview
The MSO8000HD-FILTER adds a digital filter designer — apply custom FIR and IIR filters to captured waveforms for signal extraction and noise rejection.
When standard bandwidth limiting isn't enough — extract specific frequency components or reject known noise sources with full filter control. The option is enabled by a software license keyed to the oscilloscope's serial number and is permanent for the life of the instrument.
Key Features
- Custom Filter Design — Low-pass, high-pass, band-pass, band-stop with configurable cutoff and order.
- Real-Time Filtering — Apply to live acquisitions alongside the unfiltered signal.
- FIR and IIR — Choose linear phase (FIR) or sharper rolloff (IIR) topologies.
- Response Display — View filter frequency response before applying.
- Lifetime License Activation — activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
When You Need This Option
The option fits the following workflows:
- Signal from Noise — Sensor signal buried in switching noise. Design a low-pass filter to reveal it.
- Frequency Isolation — Extract a specific frequency component for amplitude/phase analysis.
Compatibility
This option is compatible with the MSO8000HD Series: MSO8804HD (8 GHz).
Frequently Asked Questions
How is this option activated?
The option is enabled by a software license keyed to the oscilloscope's serial number. After purchase, the license is registered on the UNI-T website to generate the license file, which is then loaded onto the instrument from a USB drive through the option-install menu. Refer to the oscilloscope's user manual for the step-by-step procedure.
Is the license permanent, or does it require renewal?
The license is permanent — a one-time purchase that stays active for the life of the instrument. No subscriptions, no annual renewals, and no expiration.
