MSO8000HD-JITTER Advanced Jitter Analysis and Eye Diagram Option

MSO8000HD-JITTER Advanced Jitter Analysis and Eye Diagram Option

$2,999.00 USD
$2,999.00 USD
促销 售罄

Overview

The MSO8000HD-JITTER adds advanced jitter analysis and eye diagram measurements for signal integrity assessment in high-speed serial links and clock systems.

For PCIe, USB, HDMI, DDR, or custom serial links — decompose timing variations and verify receiver requirements with eye diagrams. The option is enabled by a software license keyed to the oscilloscope's serial number and is permanent for the life of the instrument.

Key Features

  • Jitter Decomposition — Separates RJ, DJ, PJ, DDJ, and DCD for root-cause analysis.
  • Eye Diagram — Statistical eye from serial data for signal quality — eye height, width, mask margin.
  • Bathtub Curve — BER vs. sampling position for link margin prediction.
  • Clock Jitter — Period jitter, cycle-to-cycle, and TIE for clock characterization.
  • Lifetime License Activation — activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.

When You Need This Option

The option fits the following workflows:

  • Serial Link Validation — Intermittent bit errors. Generate eye diagram for quality assessment, decompose jitter to find the source.
  • Clock Characterization — Measure period/cycle-to-cycle jitter on an oscillator for PLL and data converter requirements.

Compatibility

This option is compatible with the MSO8000HD Series: MSO8804HD (8 GHz). The same capability is offered on other UNI-T oscilloscope families: MSO7000X, UPO7000L.

Frequently Asked Questions

How is this option activated?

The option is enabled by a software license keyed to the oscilloscope's serial number. After purchase, the license is registered on the UNI-T website to generate the license file, which is then loaded onto the instrument from a USB drive through the option-install menu. Refer to the oscilloscope's user manual for the step-by-step procedure.

Is the license permanent, or does it require renewal?

The license is permanent — a one-time purchase that stays active for the life of the instrument. No subscriptions, no annual renewals, and no expiration.
