MSO8000HD-NET 10BASE-T, 100BASE-TX Ethernet Bus Analysis Option
MSO8000HD-NET 10BASE-T, 100BASE-TX Ethernet Bus Analysis Option
Overview
The MSO8000HD-NET adds 10BASE-T and 100BASE-TX Ethernet bus triggering, decoding, and search for protocol-level frame analysis. The option is enabled by a software license keyed to the oscilloscope's serial number and is permanent for the life of the instrument.
Key Features
- Ethernet Frame Decode — Trigger and decode Ethernet frames including preamble, MAC addresses, type/length, data, and FCS.
- Error Detection — Identifies FCS errors, runt frames, and jabber conditions.
- Triggering — Trigger on MAC addresses, frame types, or specific data patterns.
- Lifetime License Activation — activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
When You Need This Option
The option fits the following workflows:
- Embedded Ethernet — Debug Ethernet communication in industrial or embedded systems.
- Network Troubleshooting — Capture and decode Ethernet frames to diagnose communication failures.
Compatibility
This option is compatible with the MSO8000HD Series: MSO8804HD (8 GHz).
Frequently Asked Questions
How is this option activated?
The option is enabled by a software license keyed to the oscilloscope's serial number. After purchase, the license is registered on the UNI-T website to generate the license file, which is then loaded onto the instrument from a USB drive through the option-install menu. Refer to the oscilloscope's user manual for the step-by-step procedure.
Is the license permanent, or does it require renewal?
The license is permanent — a one-time purchase that stays active for the life of the instrument. No subscriptions, no annual renewals, and no expiration.
