Overview
The MSO8000HD-PCIe2 adds PCIe Gen 1/2 protocol triggering, decoding, and search for PCI Express link training, TLP/DLLP packets, and data transfers. The option is enabled by a software license keyed to the oscilloscope's serial number and is permanent for the life of the instrument.
Key Features
- PCIe Protocol Decode — Trigger and decode PCIe Gen 1/2 transactions.
- Link Training — Capture and decode LTSSM state transitions.
- TLP/DLLP Decode — Transaction and data link layer packet decoding.
- Lifetime License Activation — activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
When You Need This Option
The option fits the following workflows:
- PCIe Debug — Diagnose link training failures or enumeration issues.
- Data Transfer Analysis — Decode TLP packets for data transfer verification.
Compatibility
This option is compatible with the MSO8000HD Series: MSO8804HD (8 GHz).
Frequently Asked Questions
How is this option activated?
The option is enabled by a software license keyed to the oscilloscope's serial number. After purchase, the license is registered on the UNI-T website to generate the license file, which is then loaded onto the instrument from a USB drive through the option-install menu. Refer to the oscilloscope's user manual for the step-by-step procedure.
Is the license permanent, or does it require renewal?
The license is permanent — a one-time purchase that stays active for the life of the instrument. No subscriptions, no annual renewals, and no expiration.
