MSO8000HD-USB2 USB2.0 Analysis Option
MSO8000HD-USB2 USB2.0 Analysis Option
Overview
The MSO8000HD-USB2 adds USB 2.0 bus triggering, decoding, and search — protocol-level analysis of USB transactions (setup, data, status, handshake packets). The option is enabled by a software license keyed to the oscilloscope's serial number and is permanent for the life of the instrument.
Key Features
- USB 2.0 Protocol Decode — Trigger and decode USB 2.0 transactions at the packet level.
- Transaction Visibility — See setup, data, status, and handshake packets decoded on the waveform.
- Error Detection — Identifies CRC errors, timeout violations, and protocol errors.
- Lifetime License Activation — activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
When You Need This Option
The option fits the following workflows:
- Device Debug — Decode USB 2.0 transactions to debug enumeration failures or data transfer errors.
- Protocol Analysis — Capture and decode USB traffic between host and device for protocol compliance.
Compatibility
This option is compatible with the MSO8000HD Series: MSO8804HD (8 GHz).
Frequently Asked Questions
How is this option activated?
The option is enabled by a software license keyed to the oscilloscope's serial number. After purchase, the license is registered on the UNI-T website to generate the license file, which is then loaded onto the instrument from a USB drive through the option-install menu. Refer to the oscilloscope's user manual for the step-by-step procedure.
Is the license permanent, or does it require renewal?
The license is permanent — a one-time purchase that stays active for the life of the instrument. No subscriptions, no annual renewals, and no expiration.
