USG5000-PM Pulse Modulation Option
USG5000-PM Pulse Modulation Option
Overview
The USG5000-PM adds pulse modulation for pulsed RF signals used in radar, electronic warfare, and pulsed measurement applications. The option is enabled by a software license keyed to the RF signal generator's serial number and is permanent for the life of the instrument.
Key Features
- Pulse Modulation — Configurable pulse width, period, and duty cycle.
- Internal/External Trigger — Pulse timing from internal generator or external sync.
- Fast On/Off Ratio — Clean edges and deep off-state suppression.
- Lifetime License Activation — activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
When You Need This Option
The option fits the following workflows:
- Radar Simulation — Pulsed RF for receiver testing and signal processing development.
- Component Testing — Test amplifier/filter response to pulsed RF.
Compatibility
This option is compatible with all USG5000M and USG5000V RF signal generators. The same capability is offered on other UNI-T RF signal generator families: USG3000.
Frequently Asked Questions
How is this option activated?
The option is enabled by a software license keyed to the RF signal generator's serial number. After purchase, the license is registered on the UNI-T website to generate the license file, which is then loaded onto the RF signal generator from a USB drive through the option-install menu. Refer to the RF signal generator's user manual for the step-by-step procedure.
Is the license permanent, or does it require renewal?
The license is permanent — a one-time purchase that stays active for the life of the instrument. No subscriptions, no annual renewals, and no expiration.
