UTx318M Infrared Medium-Range Thermal Monocular

Overview

UTx318M

Enhanced Clarity for Every Mission

Step up your game with the UTx318M—a powerful thermal monocular that delivers exceptional clarity and detail. Engineered for outdoor exploration, search and rescue, and security operations, the UTx318M is your dependable companion in the field.

The UTx318M features an 18mm lens, offering a versatile range for mid-distance detection, perfect for spotting animals, finding heat sources, or conducting perimeter scans. With a thermal sensitivity of ≤35mK, it captures even the smallest temperature differences, ensuring nothing escapes your sight.

The monocular includes stadiametric ranging, which enables you to estimate distances based on known object sizes. While laser range finding provides pinpoint precision, stadiametric ranging is a practical, lightweight solution for dynamic environments where speed and simplicity are crucial. This feature makes the UTx318M an excellent choice for diverse applications, from wildlife observation to security patrols.

Key Features

• IR Resolution: 400×300 pixels for high-quality imaging
• Lens Focal Length: 18mm for mid-range versatility
• Thermal Sensitivity: ≤25mK for exceptional detection accuracy
• Field of View (FOV): 14.6° × 11° for targeted scanning
• Range Finding: Stadiametric
• Battery Life: 6+ hours of operation
• Durability: IP67 waterproof and 2-meter drop resistance
• Additional Features: Hot Trace, Wi-Fi Live Streaming

Specifications

Documentation

• UTx318M Datasheet
• UTx318M User Manual
